Abstract

Mass cytometry, also known as CyTOF, is a newly developed technology for quantification and classification of immune cells that can allow for analysis of over three dozen protein markers per cell. The high dimensional data that is generated requires innovative methods for analysis and visualization. We conducted a comparative analysis of four dimension reduction techniques – principal component analysis (PCA), isometric feature mapping (Isomap), t-distributed stochastic neighbor embedding (t-SNE), and Diffusion Maps by implementing them on benchmark mass cytometry data sets. We compare the results of these reductions using computation time, residual variance, a newly developed comparison metric we term neighborhood proportion error (NPE), and two-dimensional visualizations. We find that t-SNE and Diffusion Maps are the two most effective methods for preserving relationships of interest among cells and providing informative visualizations. In low dimensional embeddings, t-SNE exhibits well-defined phenotypic clustering. Additionally, Diffusion Maps can represent cell differentiation pathways with long projections along each diffusion component. We thus recommend a complementary approach using t-SNE and Diffusion Maps in order to extract diverse and informative cell relationship information in a two-dimensional setting from CyTOF data.
